Oil is indirect heated for 55-65 centigrade temp. and reaching to vacuum chamber. The combination of low heat and vacuum causes water and gas to flash into steam/vapour at a lower temperature then the oil’s thermal breakdown point. This increases the exposed surface area of the oil and convert the water/gas to vapour/steam form, which is then drawn through the condenser by the vacuum pump. Here Hot vapour will cool down and collected by water tank. Water Free/Clean oil passes out from the vacuum chamber, back to the main system by discharge pump. This is a multi cycle process.
|
Model
|
Electric Power
|
Dimension L x W X H mm
|
Suction Pump & Motor
|
Discharge Pump & Motor
|
Vacuum Pump & Motor
|
Heating Load
|
Weight (Approx)
|
|---|---|---|---|---|---|---|---|
|
LVDH 50
L-1200 |
9 kw
|
1100 x 600 x 1750
|
5-10 LPM
0.38 kw |
32 LPM
1.5 kw |
100 LPM
0.38 kw |
6 kw
|
300 kg
|
|
LVDH 100
L-2400 |
14 kw
|
1250 x 600 x 1750
|
10-15 LPM
0.38/0.75 kw |
50 LPM
2.25 kw |
180 LPM
0.38 kw |
9 kw
|
425 kg
|
Electrostatic liquid / oil cleaning machine removes all types and all sizes of suspended / solid / particles / contamination from the oil including resins and oxidation products.
An Absolute Mechanical filter (AMF) machine is a filtering solid particles greater than a stated micron size. We may choose either “Nominal” or “Absolute” filtering systems.
LVDH / VDDU is a mobile compact unit to remove free, emulsified and dissolved water / moisture from the mineral/synthetic oils at low temperature under vacuum condition.
Owing to the sturdy construction, ease of operation, longer operational life, portability, minimal maintenance, ease of installation, high production rate and low cost, the offered batch of machines, oil machines & testing kits is massively demanded in the industry.
